HPT 5500 Y


HOSTAR Model HPT5500Y Hydraulic Boat Trailer for yard use, configured with the following equipment and/or specifications:

• To handle power boats and shoal draft sailboats to 53 feet
• Overall trailer length of 50 feet
• Overall trailer width of 10 feet
• Capacity of 60,000 lbs. in the yard
• 12" x 12" x 3/8" steel square tube main frame
• Frame sealed and pressure tested for air tightness
• Hydraulics:
    * Two pivoting rear hydraulic arms with extendable pads
    * Two forward extendable hydraulic arms
    * Hydraulic raising and lowering of frame (each side)
    * Front hydraulics for fore and aft leveling/lifting
    * Manual hydraulic control valves
    * 12VDC electric hydraulic power unit
    * Pilot operated double-locking valves on all cylinders
• 12 volt deep cycle marine battery
• Battery charger or power connection to tow vehicle
• Outboard hydraulically actuated walking beam suspension
• Four slide-through steel cross beams
• Cross beam pockets through and underneath frame
• Tandem axles with four 32 x 12.1 x 15 high flotation yard tires
• Expanded metal basket at front of trailer
• Two screw pad stabilizers with sockets and T-pins
• Stainless steel T-pins and hardware
• Hydraulically operated pintle draw bar
• Finish: Frame sandblasted to white steel; finished with two coats high-build epoxy primer with hardener,
             three coats high performance acrylic urethane with hardener - choice of color

Production Time: Twelve to fourteen weeks from start of construction

HPT 5500 Y

Available Options

• Galvanized arms, cross beams, parking stands only
• Stainless steel arm pivots
• Additional pair hydraulic arms
• Frame extended, priced per foot
• 12.5K electric planetary gear winch, mounted
• Solid tires in lieu of pneumatic tires
• Remote control with pendant operation, priced per hydraulic function
• Wireless remote control in lieu of pendant operaton
• Fixed goosemeck for fifth-wheel operation
• Hydraulically articulating gooseneck for fifth-wheel operation
• Reinforced aluminum cross beams
